The high-output folded-horn subwoofer is designed for use with Wavefront Series W8C touring systems, delivering deep bass, high efficiency, quick response and powerful impact. Its familiar Martin S-shaped folded horn measures over 7 feet (2.1 m) in length and couples an 18” (460 mm) long-excursion driver to the air load using a modified hyperbolic expansion profile. 4.2 Technical specifications Freq response: 38–150 Hz ±3 dB (half space), –10 dB @ 28 Hz Rated Power: 600 W into 8 ohms, 2400 W peak Sensitivity: 105 dB (half space with band-limited pink noise) Maximum SPL: 132 dB continuous, 138 dB peak (half space with band-limited pink noise) Impedance: 8 ohms nominal Crossover Freq: 150 Hz or below Crossover System: Martin Audio DX1 Loudspeaker Management System, MX4 or MX5. (See operating instructions) Connectors: 2 x Neutrik NL8 Dimensions: (W) 572 mm x (H) 1066 mm x (D incl. wheels) 1065 mm; (W) 22.5 ins x (H) 41.9 ins x (D incl. wheels) 41.9 ins Weight: 96 kg (211 lbs)
