Description

Professional wash light with 37 individually controllable 10-W LEDs in 4-in-1 QCL RGBW technology. The homogeneous color mixing, the large motorized zoom range and the Art-Net connection enable versatile applications for shows and events. GTIN: 4026397629507 Item number: 51841314 Scenes can be programmed individually directly on the control board or via an external controller and subsequently saved in the internal memory. The number of storable scenes can be adjusted flexibly. - 37 × 10 W High-Power-4in1-QCL-LEDs in RGBW version - Homogeneous, stepless color mixing - Individual control of each LED possible - PAN movement selectable between 540° or 630° - TILT movement up to 265° - Automatic position correction via feedback - Precise 16-bit positioning - Motorized zoom - Electronic dimmer - Preset colors - Stroboscope with a flash frequency of 0–30 Hz - Integrated show programs - Temperature-controlled fan cooling - Flicker-free projection - Beam angle from 2° to 50° - Power input and power output for connecting up to 8 devices Control is possible via RDM, DMX, Art-Net, stand-alone operation, music control via microphone as well as in master/slave mode. W-DMX by Wireless Solution can be retrofitted. Suitable fixtures are available for Light´J, LED PC-Control 512 and Light Captain. Power supply: 100–240 V AC, 50/60 Hz Total connected load: 530 W Protection rating: IP20 Light source: LED LED configuration: 37 × 10 W High-Power-4in1-QCL-RGBW, homogeneous color mixing Power connection: PowerCON input, blue; panel-mount version with connection cable and protective-contact plug included DMX channels: 18, 19, 20, 41 or 170 DMX input: 1 × 5-pin XLR panel-mount socket DMX output: 1 × 5-pin XLR panel-mount plug Network: Art-Net 3 via 2 × RJ-45 panel-mount connections Cooling: Temperature-controlled fan Control options: RDM, DMX, Art-Net, stand-alone, microphone control, master/slave; W-DMX by Wireless Solution can be retrofitted Available fixtures: Light´J, LED PC-Control 512, Light Captain Beam characteristic: flicker-free Beam angle: 2°–50° Beam angle at 1/2 Peak: 2°–28° Beam angle at 1/10 Peak: 8°–50° Illuminance: Narrow beam angle, Red (R): 3 m: 5874 lx, 6 m: 1655 lx Wide angle, Red (R): 3 m: 564 lx, 6 m: 146 lx Narrow beam angle, Green (G): 3 m: 11065 lx, 6 m: 3219 lx Wide angle, Green (G): 3 m: 1160 lx, 6 m: 305 lx Narrow beam angle, Blue (B): 3 m: 1666 lx, 6 m: 563 lx Wide angle, Blue (B): 3 m: 202 lx, 6 m: 54 lx Narrow beam angle, Cool white (CW): 3 m: 15461 lx, 6 m: 4527 lx Wide angle, Cool white (CW): 3 m: 1545 lx, 6 m: 408 lx Narrow beam angle, all colors: 3 m: 31814 lx, 6 m: 9366 lx Wide angle, all colors: 3 m: 3266 lx, 6 m: 859 lx Housing color: Black Dimensions: Width 44.4 cm, depth 25 cm, height 57 cm Weight: 19.00 kg Noise classification: Class 2, low noise generation Legal notices: This special-purpose product is not intended for room lighting in private households. The intended area of use is lighting for show effects. The offer is intended exclusively for commercial customers. Sale is only possible upon presentation of a business registration. For questions, the contact options provided by email or telephone are available. Payment options for existing and new customers: Payment in advance or cash payment upon collection SEPA B2B direct debit for regular customers with an active account No payment via PayPal or credit card The sale is exclusively to commercial buyers in a pure B2B transaction and excludes any warranty, unless a functional assurance is expressly provided. Functionality is guaranteed for the intended purpose of use. The devices are predominantly display units, trade-fair units, demo units or returns from shipping. The packaging may be damaged or have stickers attached. There are no safety-related defects or functional limitations. Only signs of cosmetic use, minor housing damage as well as damaged or missing shipping cartons are possible. Any express limitations will be stated in the respective offer. If an offer relates to a complete package with several identical devices or to a set consisting of different items, the stated total amount applies as the package price. It is not possible to deduct individual components, provide separate price verification or calculate a separate discount for individual items. Should a device from a package or set unexpectedly not be functional, compensation will be provided exclusively for this individual device, not for the complete package. Shipping costs within Germany and to Austria are between 6.90 EUR and 79.00 EUR depending on volume and weight. Shipping to other countries is possible on request. Delivery is made by parcel service or freight forwarding company. Inspection and self-collection in Waldbüttelbrunn are possible by prior appointment during business hours. Subject to prior sale. Contact: Frank Kraus 0931/ 4061 673 [email protected]

Specifications
