Description

For sale are two complete sets, each consisting of one bass loudspeaker and two top units. Technical data for the bass loudspeaker: Acoustic principle: bass reflex Drivers: 1 × 12" long-excursion driver Maximum sound pressure level: 127 dB Power: 1,500 W Frequency range: 38 Hz – 130 Hz Cabinet material: birch plywood Dimensions (W × H × D): approx. 520 × 420 × 430 mm Threaded plate for distance rod: M20 Weight: approx. 25 kg Finish: black textured paint Handles: 2 corner handles Transport casters: not available Front finish: acoustic foam Protection: ball-impact-resistant, powder-coated steel grille Technical data for the top units: Acoustic principle: passive 2-way line array Rated power handling: 400 watts Program power handling: 800 watts Peak power handling: 1,600 watts Drivers: 8 × 4" neodymium drivers, impregnated, as well as 1 × 1" driver on waveguide with self-resetting IPC high-frequency protection; fully equipped with neodymium drivers Sensitivity: 94 dB Maximum sound pressure level: 126 dB Frequency response: 65 Hz – 20 kHz 2-way system: yes Nominal impedance: 8 Ohm Nominal dispersion angle (horizontal × vertical): 140° × 25° Cabinet: weather-resistant, powder-coated aluminium cabinet with steel reinforcements Connectors: 2 × Neutrik NL4 Speakon, 8-pin Phoenix terminal Dimensions (W × H × D): approx. 130 × 990 × 120 mm Weight: 7 kg Available colours: Black (RAL 9005) or White (RAL 9016), each powder-coated Front finish: front grille matching the cabinet colour Protection: ball-impact-resistant, powder-coated steel grille Mounting options: 8 × M6 threaded inserts

Specifications
