Description

Projection system with 3 × 0.76" LCD-TFT panels Light output: 8000 ANSI lumens Contrast ratio: 3,000,000:1 Intended for permanent installation Laser as light source Light source lifespan: up to 20,000 hours Throw ratio: 1.7–2.8:1 Connections HDMI input 15-pin D-Sub, input and output RCA video input RCA stereo audio input S-Video input Mini-jack for audio input and output USB Type A, input RS232C via 9-pin DIN socket, input RJ45 network connection, input Suitable for ceiling mounting Dimensions W × H × D: 560 × 205 × 443 mm (22" × 8.1" × 17.4") Weight: 16 kg / 35.27 lbs Features (Extras) Compatible with Full HD signals up to 1080p Lens-shift function for flexible image alignment Eco mode Suitable for installation in 360° positions Designed for continuous 24/7 operation PJLink™ support Optionally usable with a WLAN network Compatible with wired LAN networks DICOM simulation mode The PT-MZ770LB model has a black housing.
