Description

A single 0.67-inch DLP chip is used for image projection. The system achieves a brightness of 5500 ANSI-Lumen and offers a contrast ratio of 10,000:1. WUXGA resolution with 1920 x 1200 pixels is supported; the projection ratio is between 1.25 and 2.13:1. Connections HDMI-1.4 input including MHL DVI-D input 5 x BNC RGBHV input 2 x D-Sub, 15-pin: 1 x input and 1 x output Cinch input for video signals Cinch stereo input S-Video input Mini-jack for audio input and output USB Type A and Type B as inputs RS232C input via 9-pin DIN connector Microphone input 3D-Sync output 12-V trigger output RJ45 connector with HDBaseT input Ceiling mounting is possible. The housing measures 445 x 160.2 x 330.2 mm (W x H x D), corresponding to 17.5 x 6.3 x 13 inches. The weight is 8.4 kg or 18.52 lbs. Features (Extras) Suitable for Full-HD signals up to 1080p Lens-Shift for more flexible image alignment Eco mode BrilliantColor™ LAN network integration possible Support for Crestron® software

Specifications
