Description

The LED display controller is the first device of its kind to enable display rotation. A single controller processes up to 3840 × 1080 pixels at 60 Hz. Within this capacity, any custom resolutions can be configured – ideal for particularly long or wide LED displays and changing requirements directly at the venue. Together with an A8s or A10s-Plus receiving card, a freely configurable screen setup is possible in SmartLCT. The display can be rotated to any angle, enabling a wide range of image presentations and extraordinary visual effects. The device is suitable for both rental applications and permanently installed systems, for example at concerts, live events, in control centers, at the Olympic Games and in various sports venues. Features Inputs: 1 × 6G-SDI 1 × Dual-Link-D-DVI 1 × HDMI 1.4 Pixel capacity of up to 4,140,000 pixels each. Outputs: 8 × Gigabit Ethernet 2 × fiber optic outputs. - Display rotation at any angle. - Intelligent configuration architecture for reduced preparation time on stage. - NovaStar-G4-Engine for a stable, smooth display with good depth perception and without flickering or scan lines. - Support for the new NovaStar pixel-level calibration technology for fast and efficient calibration. - Quick and straightforward manual adjustment of screen brightness. - Firmware update via the front USB port. - Multiple controllers can be cascaded for unified control. Collection possible; shipping available for an additional charge.

Specifications
