Description

Set of 4 U-frames, 36 pieces available – also available for rental Including F31 end connector. Suitable F31 tops or rigging bars are also available. The U-frame is suitable for the freestanding installation of moving heads and LED spotlights. When several frames are used on top of one another, an effective column of light can be set up for events and shows. In combination with a top section, the frame can also be used suspended. Version with 600 mm width; alternatively, the frame is also available in 100 cm width. Specifications: - Diameter of the main tube: 50 mm - Wall thickness of the main tube: 2 mm - Diameter of the braces: 20 mm - Wall thickness of the braces: 2 mm - Material alloy: EN-AW 6082 T6 (AlMgSi1) - Connection system: conical connectors with bolts and safety cotter pins - Scope of delivery: 2 connectors, 4 bolts, 4 safety cotter pins - Manufactured in accordance with DIN 4112 and DIN 4113-1 - Dimensions (W x H x D): 600 x 760 x 50 mm - Weight: 2.3 kg

Specifications
