Description

4 x B2-SUB Frequency response (-5 dB), standard / INFRA mode: - With D12: 37 Hz – 90 Hz / 32 Hz – 68 Hz - With A1: 37 Hz – 125 Hz / 32 Hz – 68 Hz Maximum sound pressure level at 1 m, full room: - D12: 139 dB - A1: 136 dB SPLmax peak measured with a pink-noise test signal and crest factor 4. Input level for 100 dB SPL at 1 m: –20 dBu / –19 dBu Nominal impedance: 4 ohms Power handling (RMS / peak 10 ms): 600 / 2400 W Connection: NL4, contacts 2+ / 2–
