Description

4K UHD output with a maximum resolution of 3840 × 2160. The unit weighs 0.57 kg. Video decoding: - Native 4K@60p decoding with Dolby Vision and HDR10+ - Single-stream decoding: 4K or 1080p60 - Dual-stream decoding: 1080p60 Media compatibility: - 4K video codecs: H.265 and H.264 - Containers for 4K H.265/H.264 files: .ts, .mov, .mp4, .mkv - Full HD codecs: H.265, H.264 (MPEG-4 Part 10) and MPEG-2 - Full HD containers: .ts, .mpg, .vob, .mov, .mp4, .m2ts and .wmv - Images supported up to 4K: BMP, JPEG and PNG - Audio formats: MP2, MP3, AAC and WAV; AC3 is passed through HTML5 playback is supported through a hardware-accelerated engine. Full-screen and modular HTML5 content can be reproduced at resolutions up to 4K, including overlays with Full HD or high-bandwidth 4K video. Supported output resolutions: - 4K: 4096 × 2160, 3840 × 2160 and 3840 × 600 - Upscaling to 3840 × 2160 at 24/25/29.97/30p - Additional formats: 1920 × 1080, 1920 × 1200, 1600 × 1200, 1440 × 1050, 1440 × 900, 1360 × 768, 1280 × 1024, 1280 × 960, 1280 × 800, 1280 × 768, 1280 × 720, 1024 × 768, 800 × 600, 720 × 576, 720 × 480 and 640 × 480 H.265 compression enables smaller files while maintaining better content quality compared with H.264. The 4K video engine combines native Dolby Vision and HDR10+ decoding, 4K upscaling, dual 1080p playback and advanced scaling technologies. BrightWall provides frame-accurate synchronization of video playback across several displays. Autowall uses HTML5 capabilities to create multimedia video walls. With Zones, different media formats can be shown on one display, while Mosaic Mode allows multiple lower-resolution videos to play simultaneously and combine into the player’s maximum output resolution. IP Streaming enables playback of streamed media. An IP streaming server can deliver streams from local storage, while the Encoding Server supports encoding, mixing and encryption of IP streams. Interactive equipment can be connected through various interfaces, including GPIO, IR and UDP. Live Feeds support Live Data, Live Text, MRSS, Twitter, Flickr and other sources. Users of the BrightSign Network can apply media and player tags for targeted content distribution. The BrightSign App allows digital signage updates from an iOS device. Sign Preview provides a preview of presentation playback in BrightAuthor. Remote Snapshot makes it possible to capture the current display playback remotely. BrightPlates simplifies digital-signage creation with templates. Networking functions are provided for updating, managing and scheduling signage. B-deploy enables simultaneous setup and deployment of multiple players. Extended Thermal operation is supported in ambient temperatures from 0° to 70° C, with up to 90% relative humidity, non-condensing. Compatible software: BrightAuthor Connections / interfaces: - External microSD slot supporting SDHC and SDXC - SDHC cards up to 32 GB - SDXC cards up to 2 TB - M.2 SSD PCIe interface - 12-pin Phoenix GPIO connector with 8 bi-directional GPIOs - 3.5 mm IR input/output - 3.5 mm audio output: analog or SPDIF digital, not simultaneously - HDMI 2.0a output - Gigabit Ethernet - M.2 E-keyed connector for Wi-Fi/Bluetooth - Connector for an external Wi-Fi antenna

Specifications
