Description

General information: The device operates with the DVCAM format and records onto Magneto-Optical Disks (MO-Disk). For signal output, analog connections (Composite and S-Video), SDI (Serial Digital Interface), as well as DV via Firewire/i.LINK are available. Recording and playback functions: DVCAM in Standard-Play mode and DV in SP and LP recording are supported. Audio recording is performed at 16 Bit and 48 kHz; 4-channel audio recording is possible. SMPTE as well as Drop-Frame and Non-Drop-Frame modes are available for timecode processing. Video specifications: The resolution is 720 x 576 pixels in PAL and 720 x 480 pixels in NTSC format. PAL is processed at 25 frames per second, NTSC at 29.97 frames per second. The color space is analog as YCbCr 4:2:2 and, for SDI, according to ITU-R BT.601. The viewing angle is 90 degrees. Connections: For analog signals, Composite Video, S-Video, as well as audio connections in XLR and RCA format are provided. Digital output is via SDI (BNC) or DV (Firewire/i.LINK). There is also a connection for a control unit. Dimensions and weight: Dimensions (W x H x D): approx. 427 x 130 x 461 mm Weight: approx. 11.2 kg The sale includes an ML-Case. The device is in very well-maintained condition. Only the display has suffered an impact; however, this does not impair its use or operation. The sale is exclusively intended for commercial buyers and is made with the exclusion of any warranty. A proper invoice will be issued. Collection in Aachen is possible. Alternatively, shipping can be arranged for an additional charge.

Specifications
