Description

Selling an active Shure UA845 UWB-E antenna and power splitter for the frequency range of 174–1805 MHz. Shipping is possible. The wideband splitter for VHF and UHF is used to expand a wireless microphone system. It distributes one antenna pair to multiple wireless receivers. Signal losses caused by the splitting are actively compensated. Up to four diversity receivers can be connected; a cascade output is also available. Features Expandability: The UA845 UWB-E was developed for extensive wireless systems. One antenna pair can supply up to four wireless receivers. A fifth receiver or another antenna splitter can also be connected via the cascade output. Compatibility: The splitter is compatible with all Shure wireless receivers operating in the same frequency range. Cascading: Two cascade outputs allow the connection of an additional antenna splitter or a fifth wireless receiver. This also allows a larger wireless system to be operated with just one antenna pair. The IEC power cascading allows several splitters and UR receivers to be connected to the power supply using just one power cable. Technical data Frequency range: 174–1805 MHz Integrated power supply
