Description

Input voltage: 240 VAC at 50/60 Hz Dimensions: 532 x 220 x 315 mm (L x W x H) Weight: 11.4 kg Operation and programming: Signal-pin OUT: Pin 1 (Earth), Pin 2 (-), Pin 3 (+) Available DMX modes: 4, 6 or 8 channels Signal input: 3-pin XLR-HD, male Signal output: 3-pin XLR-HD, female Electromechanical effects: 40 RGBW 4-in-1 LEDs, 10 W each Colour mixing: RGBW Colour space: 16.7 million additive colours Beam angle: 45° Refresh rate: 3.0 kHz Dimmer: 0–100% Strobe: 0–20 Hz Lumens @ 2 m: Red: 5780 Lux Green: 13820 Lux Blue: 2271 Lux White: 18040 Lux Full power: 35680 Lux Mounting via quick-release fasteners for rapid installation Wireless DMX via Wireless Solutions Ingress protection: IP54 The housing supports efficient heat dissipation Control via standard DMX controller An LCD display is integrated for uncomplicated setup. Available operating modes: automatic programs, preset programs, master/slave, DMX-512, manual mode and W-DMX Housing made of powder-coated cast aluminium Connections: separate Powercon power and data connection Cooling by forced ventilation Operating temperature: -10 °C to 40 °C Included in delivery: Schuko/Powercon True1 cable, 1.5 m
