Description

1600 W system power and up to 6400 W peak power. Both units are in very good condition. The stated price applies to both units together. Shipping costs are borne by the buyer. Frequency Range (-10 dB): 28 Hz – 1 kHz Frequency Response (±3 dB): 35 Hz – 1 kHz Input Modes: Drivers Parallel / Drivers Discrete Transducer Power Rating (AES): 2400 W (9600 W peak), 2 hrs System Power Rating: 1600 W (6400 W peak), 100 hrs Maximum SPL (1 m): 30 Hz – 100 Hz: 136 dB-SPL cont avg (142 dB peak) 100 Hz – 500 Hz: 136 dB-SPL cont avg (142 dB peak) System Sensitivity (1 W @ 1 m): 30 Hz – 100 Hz: 102 dB 100 Hz – 500 Hz: 102 dB Nominal Impedance: 4 ohms in parallel-drive mode 2 x 8 ohms in discrete-drive mode LF Driver: 2 x JBL 2242H 460 mm (18 in) SVG™ drivers with 100 mm (4 in) voice coil Nominal LF Driver Impedance: 4 ohms in parallel-drive mode 2 x 8 ohms in discrete-drive mode Enclosure: Rectangular enclosure made of 16 mm (5/8 in) thick, 11-ply Finnish birch plywood suitable for outdoor use Suspension Attachment: 12 attachment points – 3 on top, 3 on the bottom, 3 on each side and 2 on the back; M10 threads Environmental: Mil-Std 810; IP-x3 according to IEC529 Net weight per unit: 161 lbs. (73 kg)

Specifications
