Description

12 dimmer channels, each rated at 2.3 kVA, residual-current circuit breaker and two 16-pole Harting connectors. 5-pin inputs and outputs are available for DMX communication; connection via CEE 32A. The weight is approximately 23 kg without case. The dimmer is in very good condition. Control is handled by a powerful computer with a Time-Processing-Unit. This allows the firing angle during phase control to be set digitally. All configuration data and cue memories are permanently stored in a non-volatile EPROM. For later software extensions, the operating system can be updated at any time by replacing the EPROM. The equipment also includes DMX control via single-channel or sequence patch, a hold function, and the option to save or recall the dimmer output values in the event of a DMX failure. A master/slave connection with other dimmers, for example within a dimmer rack, is also possible. Design as a 19" rack insert with 3 HE and twelve separately usable circuits, each rated at 2.3 kVA. The image used is for illustrative purposes only. We will be happy to send you original product photos on request. If you have any questions, please do not hesitate to contact us at any time. Thank you. The sale is exclusively to commercial customers within the EU. Any warranty and guarantee claims are excluded. An on-site inspection and/or collection is possible by prior arrangement. Shipping can be arranged on request; shipping costs are borne by the buyer. Payment is exclusively by advance bank transfer after receipt of an invoice showing VAT separately.

Specifications
