Description

Without power cable and without any additional accessories. New price: 810.- Three functions in one device: wireless battery spotlight, permanently wired spotlight and decorative floor spot. The AX5 was developed for a fast return on investment and can replace both battery-powered and wired spotlights as well as decorative floor spotlights. It thus represents another development step in the field of battery-powered lighting. 3 x 15 W RGBAW Cree LEDs Beam angle: 13° Control via Astera App, infrared remote control, Wireless DMX (Lumen Radio) or wired DMX via 5-pin XLR connectors Luminous flux: 1080 lm Colour rendering: CRI 92 Suitable for outdoor use, IP65 protection rating Dimensions: 145 x 190 x 221 mm Weight: 3.4 kg Removable multifunction bracket with tilt screw Expandable with versatile accessories such as lenses and coloured covers Features Talkback function Flicker-free operation thanks to variably adjustable PWM frequency Standby mode Seamless Runtime Theft protection with optical and acoustic alarm Dynamic Power Boost for maximum brightness at all times TruColor calibration DJ function with BPM and Flash buttons for additional special effects Emergency lighting: In the event of an interruption to the power supply, the spotlight continues operating in battery mode Battery life of up to 20 hours App control only in conjunction with Astera ART7 or AsteraBox as a CRMX transmitter Wireless DMX IP65 protection rating Astera AX5 with “Infinite Light” With the AX5, the desired duration of an event can be set directly on the device. During this period, the spotlight illuminates at maximum brightness and prevents the lighting from failing prematurely. If the mains power supply is unexpectedly interrupted, the device switches to white light and automatically continues operating with the integrated battery. TruColor calibration and video tools TruColor calibration ensures consistent colour reproduction in different applications. Exact colour temperatures can be set and standard filters reproduced. Adjustable PWM frequencies are available for video and film productions to prevent flicker. In addition, the green-magenta balance can be corrected, which can reduce the workload during post-production. Practical functions In the AX5, three 15 W RGBAW LEDs work together with high-precision Gaggione lenses. Efficient flood and wall-wash filters can be securely attached via the Clip-In system. The bracket is removable. Waterproof PowerCON True1 and XLR connectors are available for connection. Technical data Optical LED chips: RGBAW LED power: 45 W Luminous flux: 1080 lm Illuminance: 4800 lx at 2 m CRI: 92 Strobe frequency: 0–25 Hz Beam angle: 13° Pixel: 1 Electrical Battery: Samsung lithium-ion Battery life: 70% capacity after 300 charging cycles Battery runtime: up to 20 hours LED lifetime: 50,000 hours Rated charging time: 5 hours Input voltage: 90–260 V, 50–60 Hz Power IN/OUT: PowerCON True1 Control Wireless module: 865–870 MHz | 902–928 MHz | 2.4 GHz Range: 300 m DMX: CRMX, W-DMX and 5-pin XLR inputs and outputs Mechanical Housing: aluminium Aluminium housing with plastic protective ring Protection rating: IP65 Relative humidity: 0–100 % Operating temperature: 0–40 °C Weight: 3.4 kg Dimensions (W x D x H): 114 x 120 x 59 mm

Specifications
