Description

**Features** - Video encoding up to 1080p at 60 fps in H.264/MPEG-4 format - 2-channel stereo audio encoding with up to 24 Bit and 48 kHz - MPEG-4 bit rates from 32 to 256 kbps - Recording via USB and SD card interfaces: supports SD, SDHC and SDXC cards as well as USB storage, NFS, CIFS and SMB - 3G-SDI video input and output according to SMPTE-259/292/296/424, 10 Bit, Single Link 4:2:2 and 4:4:4, via BNC and HDMI - Compatible with RTMP, RTSP for up to 10 clients, RTMPE, RTMPS, HTTPS as well as RTP/UDP Unicast and Multi-Unicast - AV mute with the option to upload your own graphics for pre-live feeds **Technical specifications** - Inputs: 1x HDMI / 1x SDI / 1x 3.5-mm mini-jack - Outputs: 1x HDMI / 1x SDI / 1x 3.5-mm mini-jack - Data connections: 1x USB-A for storage media / 1x Micro-USB for configuration / 1x SD card slot for SD, SDHC and SDXC - Supported video formats: (2K) 2048 x 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 (HD) 1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 (HD) 1080i at 25, 29.97 and 30 (HD) 720p at 50, 59.94 and 60 (SD) 525i and 625i - Video encoding at 100 kbps to 20 Mbps, resolutions up to 1080p60 - Audio encoding from 32 to 256 kbps, 32, 44.1 and 48 kHz, 2-channel stereo, MPEG-4 AAC-LC - Digital audio inputs and outputs: 2 channels, integrated 24-Bit SDI/HDMI audio, 48 kHz sampling rate, synchronous - Network interface: 10/100/1000 Ethernet via RJ-45; integrated web server for configuration and control - Operation via Stream button, Record button or web user interface - Power supply: 100 to 240 V, 50/60 Hz universal input as well as +5 to 20 V DC, maximum 13 W - Dimensions (W x D x H): 178 x 140 x 26 mm - Weight: 0.4 kg Purchase on invoice with VAT shown is possible. Collection with the option of testing beforehand can be arranged by appointment in 55294 Bodenheim. Collection is free of charge; insured shipping and packaging will be charged additionally. Feel free to also take a look at the other offers in our account.

Specifications
