Description

I am offering a complete conference system. When removed from its previous environment, the set was fully functional. Testing during the inspection is of course possible. Scope of delivery: ➜ RealPresence Group 310 conference system ➜ EPTZ-2 Eagle Eye Acoustic Camera ➜ Remote control ➜ Original replacement battery for the remote control ➜ Power supply Technical data Video standards and protocols • H.261, H.263, H.264 AVC, H.264 High Profile, H.264 SVC and RTV • H.239/BFCP for the joint display of content • H.263 and H.264 Video Error Concealment for suppressing image errors Video inputs 1 x HDCI 1 x HDMI 1.3 1 x VGA Video outputs 2 x HDMI 1.3 Video resolutions for people • 1080p at 60 fps from 1740 Kbit/s • 1080p at 30 fps from 1024 Kbit/s • 720p at 60 fps from 832 Kbit/s • 720p at 30 fps from 512 Kbit/s • 4SIF/4CIF at 60 fps from 512 Kbit/s • 4SIF/4CIF at 30 fps from 128 Kbit/s • SIF (352 x 240) and CIF (352 x 288) from 64 Kbit/s • QSIF (176 x 120) and QCIF (176 x 144) from 64 Kbit/s • w288p from 128 Kbit/s • w448 from 384 Kbit/s • w576p from 512 Kbit/s Supported input resolutions for content • HD (1920 x 1080i) • HD (1920 x 1080p) • WSXGA+ (1680 x 1050) • UXGA (1600 x 1200) • SXGA (1280 x 1024) • WXGA (1280 x 768) • HD (1280 x 720p) • XGA (1024 x 768) • SVGA (800 x 600) Supported output resolutions for content • HD (1920 x 1080i) • HD (1920 x 1080p) • WSXGA+ (1680 x 1050) • SXGA+ (1400 x 1050) • SXGA (1280 x 1024) • HD (1280 x 720p) • XGA (1024 x 768) • VGA (640 x 480) Audio inputs 1 x connection for a conference system microphone array, up to 2 microphone arrays in total 1 x HDCI for the camera 1 x HDMI 1 x 3.5-mm stereo input Audio outputs 1 x HDMI 1 x 3.5-mm stereo output Other connections 2 x USB 2.0 1 x RS-232, 8-pin Mini-DIN Dimensions and weight • 28.7 cm x 3.0 cm x 12.2 cm (H x W x D) • Weight: 1.11 kg Security features • Media encryption for H.323 and SIP with AES-128 and AES-256 • Authenticated access to administration menus, web user interface and Telnet API • Support for H.235.6 • FIPS-140-2-certified encryption, certification no. 1747 • Network intrusion detection system • Configurable password policies for local accounts • Various security profiles • Whitelists for web UI and SNMP • Locking of local accounts and login ports • API access via Telnet as well as secure SSH interfaces Network functions • Support for IPv4 and IPv6 • 1 x 10/100/1G Ethernet • Auto-MDIX • H.323 and/or SIP with up to 3 Mbit/s • Lost Packet Recovery™ (LPR™) for recovering lost data packets • Configurable MTU size • RS-232 with API support • Integration with Microsoft® Office Communications Server • Support for Microsoft® Image Composite Editor (ICE) • Compatible with Microsoft Lync and Skype for Business • Support for IBM® Sametime™ Condition and functionality can be checked directly on site before purchase. The sale is private and excludes liability for material defects. No returns and no warranty. An invoice showing VAT cannot be issued; however, a receipt is possible.
