Description

Plug-and-play solution for live productions and video conferences: SDI and HDMI signals are converted into a USB 3.0 signal for the computer. Both inputs also feature an active loop-through output. This allows the signals to be forwarded to additional monitors, mixers, or other devices. 3G/HD-SDI input with active loop-through output (up to 1080p50/60) HDMI 2.0 input with active loop-through output USB 3.0 output for the computer, backward-compatible with USB 2.0 Power supplied directly via the USB connection Supports common applications such as Zoom, Skype, OBS Studio, and other software Signal overview HDMI 2.0 Input including active loop-through output Supports HDCP 1.4 and 2.2 Frame rates from 23.98 to 60.00 Video formats from 480i/p and 576i/p up to 3840 × 2160 at 50/59/60 A 4096 × 2160 signal is accepted, with the side areas of the image cropped 3G/HD-SDI Input with active loop-through output Supported standards: SMPTE 296M, 274M, 259M, and 425M (3G Level A) Frame rates from 23.98 to 60.00 Video formats from 480i/p and 576i/p up to 1080p at 50/59/60 USB 3.0 Backward-compatible with USB 2.0 With USB 3.0, video formats up to 1080p60 are supported With USB 2.0, video formats up to 720p60 are possible
