Description

For Sale Compact LED fixture from Company NA’s “Multi” family, featuring three independently controllable pixels. Each pixel is equipped with 64 RGB single-chip LED engines; the specifications list a total of 216 LEDs. The unit is intended for stage flood lighting and can also be used as a colour-changing LED blinder or as part of a decorative installation. With an approximate length of 300 mm, this is a compact version of the MultiStar HO. The remaining dimensions and available control options are the same. Several operating modes are supported: two parametric modes with 17 or 24 channels, full-fixture control using 3 or 6 channels, and individual pixel control with 9 or 18 channels for managing each LED group separately, along with other functions. Technical Specifications LED count: 216 units, arranged in 3 diode groups (pixels) Colours: 3 – red, green and blue Beam spread: 120° Average colour wavelength (manufacturer rated): red – 620 nm, green – 530 nm, blue – 470 nm Control: BMX-512 Refresh rate: 1200 Hz Dimming control: 16-bit or 8-bit AC power: 100–240 V, 48 / 62 Hz, 60 W Cooling: air cooling with fan Operating temperature: -20 to +40°C DMX channels: 3–24, depending on the selected control mode Fixture dimensions: L293 × H89 × W97 mm Weight: 2.1 kg DMX connectors: XLR5 F/M input and output Power connectors: powerCON 20A blue/grey input and output €245.00 excluding VAT (MwST) per unit Good used condition; demo equipment. 42 units available. Manual: https://tinyurl.com/y24yj26z
