Description

The projection system uses three 0.59" LCD-TFT panels and achieves a brightness of 4000 ANSI-Lumen. In energy-saving Eco mode, 2800 ANSI-Lumen are available. The WXGA resolution is 1280 x 800 pixels. A laser is used as the light source. The specified service life is 20,000 hours and can reach up to 30,000 hours in Eco operation. Thanks to the throw ratio of 0.28–0.37:1, the device is suitable for short-throw projection. Connections - 3 HDMI inputs - D-Sub 15-pin: 2 connections, each serving as an input and output - Cinch video input - Cinch stereo input - S-Video input - 3 mini-jack connections for audio, input and output - Sync input and output - Microphone input - USB input - RS232C input via DIN 9-pin - RJ45 network connection - Suitable for ceiling mounting The dimensions are 356 x 133 x 395 mm (W x H x D), corresponding to 14" x 5.2" x 15.6". The weight is 5.8 kg or 12.79 lbs. Features (Extras) - Playback of Full-HD signals with 1080p possible - Energy-saving Eco mode - Kensington security slot - Password protection - PJLink™ support - Suitable for W-LAN networks - Support for LAN networks - Design for short projection distances - Compatible with Crestron® software - AMX support

Specifications
