Description

Robust COB LED fixture for versatile applications. The beam angle can be flexibly adjusted using the included magnetically attached lenses. An integrated 6.25" holder accommodates colour filters and other accessories. Thanks to its fanless design, the unit operates completely silently. Operation is also flicker-free. **Highlights** - Replaceable magnetic lenses included - Integrated colour filter and accessory holder (6.25") - Neutrik powerCON® connectors for power supply and daisy-chaining - 3- and 5-pin DMX inputs and outputs - Fanless design for 100% silent operation - Flicker-free light output - D-Fi-USB compatible for wireless Master/Slave or DMX control - Durable die-cast aluminium housing **Specifications** **Optics** - Light source: RGBW with a total of 61 LEDs – 14 red, 13 green, 14 blue and 20 white LEDs - Total light source power: 160 W (3.8 A) - Expected LED lifetime: 50,000 hours - Beam angle: 23°, 35° or 48° - Field angle: 50°, 63° or 85° - Illuminance at 2 m: - 23°: 3442 Lux - 35°: 2414 Lux, without lens - 48°: 1310 Lux - Illuminance at 5 m: - 23°: 519 Lux - 35°: 386 Lux, without lens - 48°: 211 Lux - Luminous flux: 4880 lm - Colour temperature: 2700 K–6500 K - CRI: 80 (warm white) **Control** - Supported protocols: DMX and D-Fi - DMX modes: 4, 6 or 11 channels **Construction/Physical** - Dimensions: 220 x 245 x 305 mm - Weight: 3.6 kg **Connectors** - Power supply: Neutrik powerCON In/Out - DMX: 3- and 5-pin XLR connectors, each In/Out **Electrical Data** - Input voltage: 100–240 VAC, 50/60 Hz, auto-ranging - Power Linking: up to 11 units at 230 VAC - Power consumption: 121 W - Current draw: 0.5 A at 230 V and 50 Hz **Certifications** - CE - MET **Included** - 23° lens - 35° lens - Filter frame - Power cable

Specifications
