Description

Technical specifications: - Housing material: Metal - Color: Black - HDCP support: HDCP 1.4 - HDMI version: HDMI 1.4b - Supported HDMI resolutions: 2160p at 30 Hz, 1080p at 50/60 Hz, 1080i, 720p, 1576i, 480p and 480i - Supported video color depths: 24 bit as well as Deep Color with 30 bit and 36 bit - Audio output: analog 2-channel or 5.1-channel audio - Maximum bandwidth: 340 MHz - Maximum HDMI transmission rate: 10.2 Gbit/s - TMDS level at input and output: 0.5–1.5 V p-p (TTL) - DDC level at input and output: 5 V p-p (TTL) - Maximum input cable length: ≤ 7 m with HDMI standard cable AWG26 - Maximum output cable length: ≤ 8 m with HDMI standard cable AWG26 - Supported audio formats: MP3, AC3, DTS, WAV, WMA, AAC, ALAC, FLAC, APE, OGG and M4A - SQ: 120 dB - Stereo isolation: 80 dB at 1 kHz - Operating temperature: 0 to 70 °C - Operating humidity: 10–80 % relative humidity, non-condensing - Storage temperature: -10 to 80 °C - Storage humidity: 5–90 % relative humidity, non-condensing - Dimensions: 138.2 × 97.5 × 21.2 mm - Weight: approx. 428 g - For further data, see pictures. Collection from our warehouse in 85131 Preith. Shipping available on request at an additional shipping cost.

Specifications
